30 Presets • 124–132 BPM • 12:15AM–2:15AM • DJ: JTL (B2B Bass → Feel The Vibe → Dark Bass Trippy) • Intensity +1 to +5 • Disco Ball Active
Neon Green#00DD44R:0 G:240 B:50 W:0
Deep Blue#2255FFR:0 G:40 B:255 W:0
Electric Purple#8833CCR:140 G:0 B:220 W:0
Hot Magenta#EE0077R:250 G:0 B:120 W:0
Cyan#00CCCCR:0 G:220 B:220 W:0
Energy Range
+1 Underground+2 Groove+3 Locked In+4 Filthy+5 Maximum
Final Shift → Dark Bass Trippy fades to pure Red "Lets Go Red" @ 2:15AM
04
Techno Red
15 Presets + 5 Utility • 130–145 BPM • 2:15AM–3:15AM • DJ: JTL "Lets Go Red" B3B • Intensity +1 to +5 • Disco Ball + Fire Effects
Deep Red#CC0000R:255 G:0 B:0 W:0
Bright Red#FF1100R:255 G:10 B:0 W:0
Burning Orange#EE5500R:255 G:80 B:0 W:0
Fire Orange#DD3300R:255 G:50 B:0 W:0
White Strobe#FFFFFFR:0 G:0 B:0 W:255
Energy Range
+1 Smolder+2 Ember+3 Blaze+4 Inferno+5 Meltdown
Fixture Layout — 8× Betopper LM70SR + 1× Disco Ball Head (D1)
DANCE FLOOR / CROWD
F5
↓ back
F6
↓ back
F7
↓ back
F8
↓ back
DJ BOOTH
F1
F2
F3
F4
↑ toward crowd
D1
🩩
BACK WALL
DISCO BALL
D1 → DISCO ONLY
Fixture Position Notes — All 9 Heads on Floor
F1, F2, F3, F4 (Behind DJ — Group A): Mounted on floor in a line behind DJ booth, all facing TOWARD the crowd. Beams project upward and forward over the dance floor. Pan sweeps side-to-side freely. Tilt limited — do NOT project directly into dancers' faces. Keep beams angled upward at 60°–90° from horizontal. These provide the main backlight and silhouette effects.
F5 & F6 (Left Side — Group B): Mounted on floor along the left wall, beams aimed toward the BACK WALL. F5 is positioned further from the back wall, F6 closer. They create side-wash and cross-light effects. Pan sweeps along the left wall. Tilt limited to avoid dance floor projection.
F7 & F8 (Right Side — Group C): Mounted on floor along the right wall, beams aimed toward the BACK WALL. Mirror of F5/F6. They create matching side-wash from the right. Pan sweeps along the right wall.
D1 (Disco Ball Head — Behind DJ, Back Wall): Mounted on floor directly against the back wall behind the DJ booth, pointing STRAIGHT UP at the disco ball hung directly above. This fixture does NOT move — it stays locked on the disco ball at all times. Color changes only. This is the ONLY fixture that illuminates the disco ball.
Disco Ball: Hung at ceiling level directly above D1, behind the DJ booth. When D1 is active, the disco ball scatters light across the entire venue.
Movement Rule: All heads on floor. F1–F4 face the crowd — keep tilt conservative to avoid blinding dancers. F5–F8 aim toward back wall. D1 is always static. When in doubt, keep beams pointed upward.
